Bunker reloader BNP-40 grain store
Optimizes the work of the harvester in the field, saves time and money. Key Features
- Required tractor power - from 250 hp
- Body volume - 40 m³
- Payload - 29 tons
Why us
Performance calculator
Performance calculator
There are many features that need to be calculated for an accurate analysis of the effectiveness of agricultural machinery, so for a detailed description, our specialists will perform all the necessary calculations, taking into account your specifics.
Demoshowcase
Demoshowcase
You can sign up for future demos using the form below, or request a demo on your land.
Lending
Lending
Lending from PrivatBank or Oschadbank. Get the possibility of lending at a reduced interest rate from PrivatBank, or the development of the loyalty program of state support for Ukrainian farmers from Oschadbank.
Service
Service
Our products are fully subject to warranty and post-warranty service. To quickly return to the field, it is enough to contact the service department, where you can get qualified help.
Specifications
| Hopper discharge speed | 6,5 min |
| Required tractor power | from 250 hp |
| Full weight | 40 000 kg |
| Curb Weight | 11 000 kg |
| Body capacity | 40 m3 |
| Carrying capacity | 29 000 kg |
| Width | 3 450 mm |
| Length | 10 800 mm |
| Total height | 3 940 mm |
| Высота в рабочем состоянии | 5 240 mm |
| Loading height | 3 350±30 mm |
| Discharge height | 3 600 - 4 300 mm |
| Suspension | tridem, three-axle, dependent with leaf springs and reaction bars |
| Wheel track | 2 400±2/2 500±2 mm |
| Wheels | disk 16.00х22.50/20.00х26.50 |
| Tire type | tubeless |
| Tire size | 560/60 R22.5, 600/55 R26.5, 650/55 R26.5 |
| Type of brakes | hydro/pneumatic |
| Type of brake power | tractor system |
